Alber E-Fix Power Add-On System

AlberSKU: 42/E35

Model: E35


e-fix – the small compact electric wheelchair

Turn your manual wheelchair into a compact electric wheelchair with the e-fix add-on drive. The drive can be individually programmed and can therefore be adapted perfectly to your personal needs. The electric add-on drive is the simple way to increase your freedom of movement. The e-fix also allows you to cover greater distances and handle slopes effortlessly.

Stay flexible - two wheelchairs in one!

E-fix flexibel 2-in-1If the situation requires it, the e-fix can also be easily moved by hand: You uncouple the drive wheels with a handle and your wheelchair can be pushed by hand as usual – either using the push rims or by an attendant. The manual wheels can usually still be used too.

Requires little space – simply take it with you everywhere you go.

The components of the lightweight and compact add-on drive can be quickly removed from the wheelchair without the need for tools. Everything is quickly and easily arranged. Even in the smallest of trunks.

Control unit

E-fix control unitThe modern, flat design of the control unit offers simple operation and perfect ergonomics.

  • TFT color display showing capacity and range
  • Speed selection (0.5 – 6 km/h)
  • On/Off button, horn and spotlight
  • Removable handrest
  • Other adjustment options for individual adaptation via programmable parameters

Battery pack

E-fix batteryThe lightweight and small powerhouse – extremely compact, can be removed in a flash.

  • Efficient lithium-ion cells for a long life
  • Range of up to 16 km with 6.0 Ah battery pack (depending on ground surface, weight of the person, temperature, wheelchair settings and terrain)
  • Easy to take out and put back in again
  • Weight: just 2.1 kg
  • Integrated carrying handle
  • Optional: 7.5 Ah battery pack with range of up to 20 km (standard with E36 version)
  • The battery pack can be charged when fitted on the wheelchair or when removed
  • Socket for control unit and battery charger plugs: Automatic contacting using magnet (EasyConnex)

E35/E36 drive wheel

E-fix drive wheelMotor, brake, gear and coupling have been integrated in the drive wheel in the wheel hub. This allows the wheels to be easily fitted and removed without any tools.

  • Available in various wheel sizes
  • Simply uncouple e-fix wheels for manual operation
  • e-fix increases the width of the wheelchair by approx. 2–5 cm

E35 version

  • Weight of the person of up to 120 kg
  • Wheel size: 22" or 24", puncture-proof

E36 version

  • Weight of the person of up to 160 kg
  • Wheel size: 24", puncture-protected

Anti-tippers with swiveling and jack-up function

E-fix anti-tippersAnti-tippers come in pairs. Our anti-tippers allow us to guarantee conformity with the German Medical Devices Act.

  • e-fix anti-tippers with swiveling and jack-up function
  • Can be removed using quick-release device
  • Height and length can be adjusted
  • With automatic swiveling function for passing over curbs and thresholds
  • Jack-up function to remove the drive wheels with ease
Technical Data E35 E36
Speed 0.5 - 6 km/h
0.5 - 6 km/h
Climbing and braking ability
Up to 20%
The limit values of the wheelchair manufacturer should be observed.
Up to 15% with max. 160 kg
Up to 20% with max. 120 kg
The limit values of the wheelchair manufacturer should be observed.
Range Up to 16 km
depending on ground surface, weight of user, temperature and topography
Up to 18 km
depending on ground surface, weight of user, temperature and topography
Wheel Sizes 22” and 24”
Max. weight of the person
120kg 160kg
Max. permitted total weight
170 kg
(e-fix, wheelchair and wheelchair driver)
210 kg
(e-fix, wheelchair and wheelchair driver)
Batteries 36 V; 6,0 Ah; 216 Wh
36 V; 7,5 Ah; 270 Wh
Drive Wheel 7.9kg 7.8kg
Battery Pack
2.1kg 2.1kg
Control unit
0.6kg 0.6kg
0.8 kg
Total weight of all components
19.3 kg
19.1 kg



24 months (12 months for the batteries) from the date of purchase, and covers faulty material and processing defects.

The warranty does not include:· natural wear and tear, damage caused by improper use, forced damage, unauthorized changes made on the device and/or its accessories.

Country of Origin Germany

e-fix is CE-compliant according to the European Medical Devices Directive (MDR) 2017/745 and is tested and certified on a voluntary basis by the TÜV Süd, in line with the currently valid edition of the product standard EN 12184.
