Model Number |
EIF6 |
Frame Style |
Folding |
HCPCS Code |
QXi: K0005 QX: K0004 |
Wheelchair Weight |
QXi: 28.8 lbs. QX: 28 lbs. |
Frame Material |
Aluminum |
User Weight Capacity |
265 lbs. |
Transit Approved |
Yes |
Shipping Dimensions |
33" L x 38" H x 13" W |
Average Shipping Weight |
50 lbs. |
|
|
FRAME AND FEATURE MEASUREMENTS |
Seat Widths |
14" to 20" |
Seat Depths |
14" to 20" |
Frame Angle |
N/A |
Front Seat-to-Floor Height |
12.5" to 19.5" |
Rear Seat-to-Floor Height |
12" to 19" |
Lower Leg Length Setting |
11.25" to 16.5" |
Back Height |
13" to 20" |
Angle Adjustable Backrest Adjustment Range |
-14° to +5° |
Camber |
0° and 3° |
Center of Gravity (COG) Adjustment |
QXi: 1" to 3" QX: N/A |
Tilt Range |
N/A |
|
|
OPTIONS AND ACCESSORIES |
Frame Type |
Standard Hemi |
Special Packages |
N/A |
Tilt Release Options |
N/A |
Frame Inset |
N/A |
Caster Wheels |
4" Low Profile Polyurethane 4" x 1.25" Semi Pneumatic 5" Low Profile Polyurethane 5" x 1.5" Semi-Pneumatic 6" Polyurethane 6" x 1.5" Semi Pneumatic 8" Polyurethane 8" x 1.5" Semi Pneumatic |
Caster Options |
N/A |
Hangers |
60° Swing In/Out Hanger 70° Swing In/Out Hanger 80° Swing In/Out Front Mount Elevating Legrests (Front Latch) Articulating Hanger Elevating Hanger Elevating Hanger Front Mount |
Footplates |
Composite Aluminum Angle Adjustable Aluminum |
Footplate Options |
Heel Loops Extension Tubes |
Axle |
Quick Release Steel Quad Quick Release Steel |
Axle Plate |
Standard |
Rear Wheel Type |
20" Mag Wheel 22" Mag Wheel 24" Mag Wheel 20" Lite Spoke Wheel 22" Lite Spoke Wheel 24" Lite Spoke Wheel 25" Lite Spoke Wheel 26" Lite Spoke Wheel |
Rear Wheel Tire |
Pneumatic Pneumatic with Airless Insert Full Poly High-Pressure Clincher |
Handrims |
Aluminum Anodized Plastic Coated Natural Fit - Standard Grip Natural Fit - Super Grip |
Hub Lock |
N/A |
Suspension |
N/A |
Backrest Type |
Standard Angle Adjustable |
Back Post Options |
Integral Push Handles Fold-Down Push Handles |
Backrest Options |
N/A |
Back Upholstery |
Standard Tension Adjustable Ballistic Nylon Tension Adjustable 3DX Vented J3 |
Military Service Patches |
Marines Army Navy Air Force Coast Guard Purple Heart
|
Armrests |
Padded Swing-Away Single Post Height Adjustable Standard Single Post Height Adjustable Low Flip Back Height Adjustable LITE Dual Post Flip Back Height Adjustable |
Arm Pads |
Desk Length - Classic Full Length - Classic |
Wheel Locks |
High Mount Push High Mount Pull Compact 6" Extension Handle Pair |
Seating |
Seat Sling Depth Adjustable |
Power Assist |
N/A |
Grade Aid |
N/A |
Anti-Tips |
Rear Anti-tips |
Side Guards |
Plastic - Standard Plastic - Low |
Side Guard Options |
N/A |
Positioning Belts |
1.5" Auto Buckle with Clamps Positioning Belt Side Clamps |
Tray Tables |
N/A |
Accessories |
Quickie Backpack Seat Pouch Caddy Black Spoke Guard Gel Cover Hanger/Frame Gel Cover Swing-Away Armrest Crutch Holder |
Frame Color Options |
Black Black Opal Blue Opal Candy Blue Candy Red |
Anodized Color Options |
N/A |
