Yuwell Oxygen Concentrator
Litres per minute:5LPM
Quantity:
- Complete plastic outer shell, safe and reliable
- Timing accumulating function - show total working hours through the display screen
- Press safety valve help ensure better security
- Power failure alarming function - high pressure and low pressure alarming function
- Compressor has heat protection feature that ensures the safety of the compressor and concentrator
Click to enlarge image
Content (All O2 units come with):
Yuwell Oxygen Concentrator x 1
Sterile Water 1000ml 1x
Bubble Humidifier Bottle 1x
Disposable Nasal Oxygen Cannula x 1
Specifications
| 5 Litres per minute | 10 Litres per minute | |
| Oxygen Flow | 0.5L-5L/min | 0.5L-10L/min |
| Oxygen Concentration | 95.5%±4 | 95.5%±4 |
| Output Pressure | 45kPa ± 4.5kPa (6.52 psi ± 0.65 psi) | 62kPa ± 4.5kPa (8.99 psi ± 0.65 psi) |
| Pressure Relief Mechanism Operational at | 250kPa±25kPa | 250kPa±25kPa |
| Operation Noise Level | ≤53dB(A) | ≤60dB(A) |
| Input Power | 500VA | 850VA |
| Minimum Operating Time | 30 minutes | 30 minutes |
|
Power Supply |
AC220V±10%, 50Hz | AC220V±10%, 50Hz |
|
Size |
445×372×690mm | 445×372×690mm |
| Weight | 28kg | 33kg |
Inclusive of 1-time on-site basic servicing within 1 year from the date of purchase.
Downloads
Yuwell Oxygen Concentrator 5L/min Brochure
Yuwell Oxygen Concentrator 10L/min Brochure
